Description

Key Features

1. Advance linear actuator system [04Pc Control box, 01Pc Handset, 01 Pc. Nurse Control System (ACP)].

2. All positions can be controlled by a wired remote hand set placed on the side rail or by ACP (attendant control panel) at the foot end.

3. Easily detachable polymer head & foot bows with buffer.

4. Extra long 4pcs. Under side Occidental style side rails with inclination degree indicators.

5. Four section ABS top.

6. Framework made up of M.S tubes.

7. Bed Mounted on 5″ Central Locking ABS Castors, Durable & quiet.

8. S.S. Telescopic I.V. Rod with 4 Location.

9. Holder for Urine Bag.

10. Sitting position adjustable.

11. Pre-treated & Epoxy Powder Coated finish.

12. Overall Approx. Size: 2060L x 900W x 470-810H mm.

13. C4 Section Mattress (IHF-2001C).

14. LED Lamp as reading lamp or under Bed lamp.

15. Positions Obtained by Hand Remote-

(i) Hi-Low

(ii) Backrest elevation

(iii) Knee rest elevation

(iv) Trendelenburg/Reverse Trendelenburg

16. Positions obtained by membrane-

(i) Hi-Low

(ii) Backrest elevation

(iii) Knee rest elevation

(iv) Trendelenburg/Reverse Trendelenburg

(v) Electric CPR for zero positioning of bed

(vi) Fowler position

17. Positions obtained/Functions on Nurse Control System (ACP)-

(i) Hi-Low with Locking function for handset

(ii) Backrest elevation with Locking function for handset

(iii) Kneerest elevation with locking function for handset

(iv) Trendelenburg / Reverse Trendelenburg with locking function for handset

(v) One button Electric CPR Position and manual CPR function for any Emergency case
